| Parameter | CZ-Φ Extruder (Small) | CZ-Φ Extruder (Medium) | CZ-Φ Extruder (Large) |
| Model | φ12, φ15, φ18, φ20, φ25, φ28 | φ30, φ35, φ40, φ45 | φ50, φ60, φ70, φ80, φ90 |
| Extrusion Material | FEP, PFA, ETFE, XETFE | ||
| Extrusion Output | 1.5kg/h～12kg/h | 15kg/h～30kg/h | 37kg/h～160kg/h |
| Finished Wire OD Range | φ0.08～1.4mm | φ0.25～10.0mm | φ5.0～35.0mm |
| Production Speed | 0～300 m/min | 0～300 m/min | 0～150 m/min |
| Conductor Structure | Single conductor or stranded conductor | Stranded conductor, stranded core wire | |
| Insulation Structure | Single insulation, co-extrusion, 2-layer tandem extrusion, 3-layer tandem extrusion, stripe extrusion | ||
| Applicable Wire Type | Round wire, flat wire, ribbon cable | ||
| Concentricity | ≥95% | ≥90% | |
| Power | Siemens motor, Siemens servo, Yaskawa servo | ||
| Controller | Siemens, Yaskawa | ||
| Control System | Advantech IPC, Siemens system | ||
| Automation Function | Full line synchronous auto control, non-stop auto reel change, auto reel loading & unloading, automatic defect removal | ||
| Testing Instrument | SIKORA, ZUMBACH, Proton, TAKIKAWA | ||
| Core Features | 1. High configuration, low energy consumption, and high production efficiency; 2. High-precision screw, excellent plasticization, resulting in high-gloss surface finish on the extruded wires and smooth, continuous wire core extrusion; 3. All electrical components are from top international brands, ensuring good production line stability, strong operational continuity, and long lifespan; 4. High temperature control accuracy and stable temperature (using Japan-RKC); 5. Gearbox teeth undergo high-frequency hardening treatment and precision grinding, resulting in wear resistance and low noise; 6. PLC-based full computer control for easier operation. |
||
