| Item | Specification |
| Application | Suitable for various cable core twisting; supports data cable twisting with untwister |
| Processing Range | Core wire Φ0.9–5.0mm, max twisted wire Φ30mm |
| Max Speed | 400RPM |
| Twist Pitch | 40–400mm (adjustable), precision ±2% |
| Twist Direction | Left, Right, S/Z switchable |
| Structure | 8-head magnetic pay-off frame, taping machine, Φ1250 cantilever twister |
| Tension Control | 5kg magnetic powder tension system |
| Drive System | 50HP Siemens main motor, Yaskawa inverter, hydraulic reel lifting |
| Mechanical Design | Alloy aluminum cantilever, Taiwan ball screw precise traversing |
| Control System | Siemens 10'' touch screen + PLC, PID adjustment, MES interface, data storage & fault display |
| Safety Device | Belt breakage detection, door interlock protection |
