Chuangzhan Intelligent Technology (Guangdong) Co., Ltd.
手机号: φ1000
Place Of Origin: China
Use: Stranding
证明: ISO
Automatic Grade: Semiautomatic
Cantilever Speed: 0-1200rpm
Supply Reel Size: 630-1000mm
Wire Reel Size: Outer Diameter 1000mm
Production Efficiency: 550rpm/Min
Center Taping Machine Tension Range: ±2
Core Wire Outer Diameter: 1.5-6mm
Twist Range: 40-400mm (Customizable)
Paper Tray Specifications: 40mm-400mm (or as Per Your Specifications)
Pay-off Tension: 2-50n
Center Taping Machine Tape Pitch Accurac: ±150g
Main Motor: 15HP Siemens Motor, Equipped with Japanese Yaskawa
Twist: S, Z direction (electronic twist direction can be switched at will)
Scope Of Application: Bus cables, drag chain cables, coaxial cables, optical fibers, electric vehicle charging cables, high-frequency data Taping and twisting of high-voltage cables, CAT5, CAT5E, CAT6, CAT6A, CAT7, CAT7A, CAT8 network cables and other multi-core high-end cables
Finished Product Performance: SIKORA,ZUMBACH,Proton,TAKIKAWA
Voltage: The twisted product has stable and reliable twist pitch and excellent impedance consistency.
The file is encrypted. Please fill in the following information to continue accessing it
| Applicable finished wire diameter range | φ0.4~35mm |
| Production line speed | 0~300m/min |
| Cantilever speed | 0~1200rpm |
| Twist range | 3~600mm(Electronic twist distance can be set arbitrarily) |
| Pay-off tension | 2~50N |
| Center taping machine tension range | ±1(Including acceleration, deceleration and stop) |
| Center taping machine tape pitch accuracy | ±150g |
| Twist | S, Z direction (electronic twist direction can be switched at will) |
| power | Siemens motor, Siemens servo, Yaskawa servo |
| Controller | Siemens, Yaskawa |
| Control System | Advantech Industrial Control, Siemens System |
| Automation | One-button start, full automatic cruising according to set parameters |
| Voltage | Applicable to your local voltage |
| Scope of application | Bus cables, drag chain cables, coaxial cables, optical fibers, electric vehicle charging cables, high-frequency data Taping and twisting of high-voltage cables, CAT5, CAT5E, CAT6, CAT6A, CAT7, CAT7A, CAT8 network cables and other multi-core high-end cables |
| Finished product performance | SIKORA,ZUMBACH,Proton,TAKIKAWA |
| Voltage | The twisted product has stable and reliable twist pitch and excellent impedance consistency. |
