| Item | Specification |
| Application | Twisting & untwisting for medical wires, data cables, military wires, HDMI, DVI, USB, CAT7 high-frequency cables |
| Speed | Max 1000RPM, normal 800RPM |
| Machining Range | Core wire Φ0.6–3.0mm, max assembled wire Φ10mm |
| Twist Pitch | 15–150mm, computer adjustable |
| Tension | 100–1500gf for core wire & tape |
| Structure | 12-head active pay-off, bundling frame, side & central taping machine, Φ630 cantilever twister |
| Drive | Chengbang pay-off motor; 15HP Siemens main motor, Yaskawa inverter |
| Mechanical Parts | Imported alloy aluminum cantilever, Taiwan ball screw, S/Z twist direction switchable |
| Control System | Siemens 10'' touch screen + PLC, PID adjustment, MES interface, data storage |
| Safety Devices | Broken tape detection, door interlock protection |
