| Item | CZ-Φ12/15/18/20/25/28 | CZ-Φ30/35/40/45 | CZ-Φ50/60/70/80/90 |
| Process Material | FEP, PFA, ETFE, XETFE | ||
| Output Capacity | 1.5–12kg/h | 15–30kg/h | 37–160kg/h |
| Finished Wire Dia. | Φ0.08–1.4mm | Φ0.25–10.0mm | Φ5.0–35.0mm |
| Production Speed | 0–300m/min | 0–300m/min | 0–150m/min |
| Conductor Type | Solid or stranded conductor | Stranded conductor, stranded core wire | |
| Insulation Structure | Single extrusion, co-extrusion, 2-layer / 3-layer serial extrusion, stripe extrusion | ||
| Applicable Wire | Round wire, flat wire, ribbon cable | ||
| Concentricity | ≥95% | ≥90% | |
| Drive System | Siemens motor, Siemens & Yaskawa servo | ||
| Controller | Siemens, Yaskawa | ||
| Control System | Advantech IPC, Siemens system | ||
| Automation Function | Whole-line synchronous control, non-stop automatic reel change, auto loading/unloading, defective point auto rejection | ||
| Inspection Equipment | SIKORA, ZUMBACH, Proton, TAKIKAWA | ||
| Main Features | High configuration & low power consumption;high-precision screw with excellent plasticization;international top electrical components;high temperature accuracy with Japan-RKC controller;high-frequency hardened & precision ground gearbox;PLC computerized control for easy operation | ||
