Chuangzhan Intelligent Technology (Guangdong) Co., Ltd.
手机号: φ60
Place Of Origin: China
Use: Extruding
Customization: Available
After-sales Service: Online Support and Overseas Services
Driven Type: Electric
证明: ISO, CE
Warranty: One-Year Warranty and Lifetime Maintenance
Screw: Single-Screw
Extrusion Material: PFA/FEP/TPE
Applicable Finished Wire Diameter Range: 5.0-35.0mm
Production Speed: 10-300m/Min
Tension Range: 5--70n
Extrusion Volume: 130kg/H-460kg/H
Pay-off Tension: 10n-100n
Take-up Tension: 10n-100n
The file is encrypted. Please fill in the following information to continue accessing it
| Extrusion materia | FEP,PFA,ETFE,XETFE |
| Extrusion volume | 37kg/h~160kg/h |
| Applicable finished wire diameter range | φ5.0~35.0mm |
| Production speed | 10~300 m/min |
| Insulation structure | Insulation, co-extrusion, two-layer extrusion, three-layer extrusion, injection molding |
| Power | Siemens motor, Siemens servo, Yaskawa servo |
| Control System | Advantech Industrial Control, Siemens System |
| Automation | Automatically control the whole machine synchronization, automatically change the reel without stopping the machine, automatically load and unload the reel, and automatically remove the defective points |
| Testing equipment | SIKORA,ZUMBACH,Proton,TAKIKAWA |
| Scope of application | Cables (BV, BVR, BYY, BVVB, RV, RVS, RVV), electronic cables, medical signal cables, new energy data cables, high-speed transmission data cables, coaxial cables, optical fiber cables, etc. |
