| Item | Specification |
| Application | Professional for high-shielding cable winding production |
| Power Supply | 380V / 50Hz |
| Structure | Φ400–500mm pay-off, 50-head winding, Φ630mm take-up |
| Tension Control | 50–2000g, Yaskawa servo drive |
| Winding Spec | 50 heads, 0.1–0.2mm copper wire, 25mm die hole |
| Running Speed | Max 800RPM, line speed 5–20m/min |
| Stranding Pitch | 5–40mm adjustable |
| Processing Wire | Core wire 1.0–5.0mm, winding copper wire 0.1mm |
| Functions | Traverse winding, meter-counting stop, broken wire auto-stop |
| Configuration | NSK bearings, fully enclosed safety cover, door interlock protection |
