| Item | Specification |
| Application | High-frequency wire twisting & untwisting for medical wire, data cable, military wire, HDMI, DVI, USB, CAT7 cables |
| Running Speed | Max 1000RPM, normal 800RPM |
| Wire Processing | Core wire Φ0.6–3.0mm, max assembled wire Φ10mm |
| Twist Pitch | 15–150mm, computer adjustable |
| Tension Range | 100–1500gf adjustable for core wire & tape |
| Machine Structure | 12-head active pay-off, bundling frame, taping machine, Φ630 cantilever twister |
| Drive System | Chengbang pay-off motor, 15HP Siemens main motor, Yaskawa inverter |
| Mechanical Parts | Imported alloy aluminum cantilever, Taiwan ball screw, S/Z twist direction switchable |
| Control System | Siemens 10-inch touch screen + PLC, PID automatic adjustment, MES data communication |
| Safety Functions | Broken belt detection, door interlock protection, data recording |
