| Parameter | Description |
| Model | 1000 cantilever computer single twister |
| Application | General core twisting, data cable with back twist machine |
| Rotation speed | Max 550 RPM |
| Wire range | Single core 1-4mm, max finished cable 20mm |
| Lay length | 40-400mm digital adjustable, tolerance ±2% |
| Twist direction | Left right S Z switchable |
| Machine parts | Payoff stand collector taping unit main machine control cabinet |
| Main structure | Steel frame bow, servo take up, Yaskawa inverter, ball screw traversing, auto bearing lubrication, hydraulic reel lift |
| Control system | Siemens touch PLC, MES connection data storage auto PID control |
| Safety | Broken tape detection door interlock |
